This Grounding Standard describes the technical requirements for grounding the SEC Distribution Network installations. SEC Distribution System extends from the MV (33 kV, 13.8 kV) feeder outlets
Standard for grounding resistance of primary distribution boxes
The grounding resistance of a primary distribution box should generally be below 0.1 ohm for system components, with a maximum of 25 ohms for the overall earth connection depending on local standards.Recommended Grounding ResistanceFor distribution boxes, the ground resistance between system parts such as the mounting plate, spindle plates, and tool cables should be less than 0.1 ohm to ensure proper safety and fault current dissipation (Atlas Copco guidelines) . For the overall earth electrode system, many installation standards recommend a maximum of 25 ohms, with multiple rods or continuous conductors used if the resistance exceeds this value (Coloria Group) .Grounding MethodsConnection to mounting plate: Attach a ground wire from the threaded studs at the bottom of the distribution box to the mounting plate, then from the mounting plate to the central grounding point .Wire sizing: Use a 5.26 mm² (10 AWG) wire in the US or 6 mm² wire elsewhere for standard grounding. For longer tool cables or multiple spindles, larger wires (e.g., 16 mm² or 6 AWG) may be required to maintain low resistance .Parallel grounding paths: When multiple spindles or long cables are involved, grounding resistances in parallel reduce the total resistance, ensuring it remains below the 0.1-ohm threshold .Installation ConsiderationsShort conductors: Keep grounding conductors as short as possible to minimize impedance and improve fault current dissipation .Equipotential bonding: Connect all structural metal parts, enclosures, and floor ground planes to form a reliable grounding network, which also reduces high-frequency interference .Material quality: Use corrosion-resistant conductors such as copper-bonded steel or high-quality copper rods to maintain long-term reliability .Compliance: Follow local electrical codes such as NFPA 70 (NEC) or the Canadian Electrical Code, and ensure grounding meets both safety and electromagnetic compatibility requirements .Safety and Functional BenefitsProper grounding ensures:Personnel safety by providing a low-resistance path for fault currents .Equipment protection against surges, lightning, and high-frequency currents .System reliability by stabilizing voltage levels and reducing electromagnetic interference . In summary, a primary distribution box should have a grounding resistance below 0.1 ohm between internal components, with careful attention to wire sizing, parallel paths, and high-quality materials, while the overall earth system should not exceed 25 ohms to comply with safety standards and ensure reliable operation.
